Description
Engine & Drivetrain
| Engine Type | ProStar 500cc, 4-Stroke SOHC Single Cylinder |
|---|---|
| Cylinders-Displacement (cc) | 33 HP |
| Fuel System | Electronic Fuel Injection |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H; Shaft |
| Drive System Type | True On-Demand AWD/2WD |
| Cooling | Liquid |
Suspension:
| Front Suspension | MacPherson Strut With 8.2 in (20.8 cm) Travel |
|---|---|
| Rear Suspension | Dual A-Arm, IRS 9.5 in (24.1 cm) Travel |
Brakes:
| Front/Rear Brakes | Single Lever 4-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
|---|---|
| Parking Brake | Park in Transmission/Lockable Hand Lever |
Tires / Wheels:
| Front Tires | 24X8-12, NS388 |
|---|---|
| Rear Tires | 24X10-12, NS388 |
| Wheels | Stamped Steel |
Dimensions:
| Bed Box Dimensions (L x W x H) | N/A |
|---|---|
| Front/Rear Rack or Box Capacity | 90 lb (40.8 kg)/180 lb (81.6 kg) |
| Fuel Capacity | 4.5 gal (17.0 L) |
| Ground Clearance | 10.5 in (26.7 cm) |
| Overall Vehicle Size (L x W x H) | 83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm) |
| Wheelbase | 50.5 in (128.3 cm) |
| Estimated Dry Weight (pounds/kg) | 701 lb (318 kg) |
Features:
| Cargo System | Lock & Ride, 6 Gal (23 L) Front Dry Storage, 2 Gal (8 L) Rear Storage |
|---|---|
| Hitch Towing Rating | 1,225 lb (555.7 kg) |
| Hitch/Type | Standard/1.25 in (3,2 cm) Receiver |
| Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
| Variants | Off-Road |
